diagnostic

Aurochart-DVC
DIGITAL VISION
CHART

Aurochart
  • Multiple Testing Distance option

  • Monitor with LED backlight

  • Multimedia Access through USB and Inbuilt Videos

  • Fixation targets and Educational charts

Aurochart

Features

  • Multidistance option(6 feet to 25 feet with 0.25 feet increment)

  • Multimedia access through USB

  • Inbuilt videos and pictures

  • Languages- English, Hindi, Tamil, Telugu, Kannada, Malayalam, Gujarati, Oriya, Punjabi, Bengali, Urdu & Arabic

  • Menu options for distance, languages, Single OPTO and Setup functions

  • Basic charts like snellen, DOTS, HOTV and child extended

  • Astigmatism, Duochrome, Amsler grid full, contrast sensitivity tests, colour vision tests, phoria tests and Aniseikonia tests

  • Fixation targets for children

  • Educational charts

  • Monitor with LED back light

  • User friendly remote control

  • Free from interference of other device remotes

  • Power saving mode

  • Wall mount and table top facility

SPECIFICATIONS
Display size 18.5 inchs (Diagonal)
Resolution 1280 x 720 Pixels
Luminance 200 cd/m2
Connectivity USB
Power Supply 100 VAC to 240 VAC
Frequency 50 or 60 Hz
Power Consumption 21 Watts
Power save mode Enables when no key press for 2 hours
Remote Control IR - wide operating range
Battery 2 x AAA
Overall size 350.9(H) x 447.2 (W) x 182.4(D) mm
OPERATING CONDITIONS
Temperature 0° C to 40° C
Humidity 10% to 85%
Gross Weight 4.89 kg
