logo
surgical

AURORING
CLINICAL QUALITY
UV ABSORBING
PMMA

Auroring
Auroring

MODIFIED CTR WITH SINGLE & DOUBLE LOOP

These rings are designed to stabilize the capsular bag in cases of damaged or missing zonules. These rings are specially designed for scleral fixation with suture.

  • Promotes circular expansion of the capsular bags

  • Stabilizes conditions during surgery

  • Improves IOL centration

  • Resists capsular shrinkage

  • Proves to be a better option in case of larger zonular dialysis and in cases of progressive zonulysis

Model Reference Overall diameter Closed diameter
CCIOL, CCIOR, CCIOLR 12.00 mm 10.00 mm
CCIIL, CCIIR, CCI ILR 13.00 mm 11.00 mm

Capsular Tension Ring

Advantages

  • Ensures stable conditions during surgery

  • Prevents Capsular Fibrosis

Auroring
Model Reference Overall diameter Closed diameter
CTR 10 12.00 mm 10.00 mm
CTR 11 13.00 mm 11.00 mm

Capsular Tension Segment

This is a zonular support device, that provides support for in-the bag IOL implantation. Its versatility enables early or late placement within the capsular bag. It can be used in cases that cannot be supported by CTRs.

  • Partial Ring with a fixation hook

  • Can be used in parts of capsule that have insufficient zonular support

  • Easy and atraumatic, placement even before phaco

  • Can be implanted with minimal capsular or zonular stress

Scleral Fixation Lens

UV Absorbing PMMA, Equiconvex Optic, Modified "C"Loop, A Constant: 118.5, ACD: 5.0 mm, 2 holes in haptics 180°

Model Optic Dia (mm) Position Holes Over all Diameter (mm) Vault Height (mm) Diopter Range
SC6530 6.50 0 13.00 0.4 6.0D to 30.0D 15.0 to 25.0 in 0.5D

Scleral Fixation Sutures

Needle Suture Material Suture Length Suture Sizes
Advanced Micro Point Spatula.
AS-000-6
Diameter 0.15mm
Length 16.0mm
Straight Needleneedle		 aurojene Polypropylene Blue Monofilament 20cm(8")suture length 6002PP
Advanced Micro Point Spatula.
AS-000-6
Diameter 0.15mm
Length 16.0mm
Straight Needleneedle		 aurojene Polypropylene Blue Monofilament 20cm(8")suture length 6002PP
Advanced Micro Point Spatula.
AS-000-6, AS-160-6
Diameter 0.15mm
Length 16mm, 5.6mm
Straight Needle, % Circle - 160°needle		 Advanced Micro Point Spatula
AS-000-6, AS-160-6
Diameter 0.15mm
Length 5.6mm, 16.0mm
Straight Needle, Circle 160°needle		 aurolene Polypropylene Blue Monofilament 30cm (12")suture length 60602PP 60692PP

  • Advanced Side Cutting Spatula needle for improved penetration through Sclera.

  • Straight Needle particularly used for Scleral IOL fixation.

  • Rectangular needle body provides excellent handling.

  • Blue monofilament polypropylene provides good tensile strength and secured knotting properties.
