| Head Inclination |
0°- 45° 0°- 210° |
0°- 45° 0°- 210°s |
| Eyepieces |
10 X Wide field (standard), 12.5 X Wide field* |
10 X Wide field (standard), 12.5 X Wide field* |
| Objectives lens |
f = 200mm |
f = 200mm |
| Magnification |
0.6x, 1.0x, 1.6x |
0.4x, 0.6x, 1.0x, 1.6x, 2.5x |
| Field of View |
30mm to 12mm |
30mm to 12mm |
| IPD |
50mm - 75mm |
50mm - 75mm |
| Diopter Adjustment |
±5 |
±5 |
| Illumination |
27W LED Lamp (Light Source) |
50W LED Lamp (Light Source) |
| Optics |
Apochromatic optics |
Apochromatic optics |
| Intensity Control |
Adjustable o to 100 maximum lux |
Adjustable o to 100 maximum lux |
| Filter |
Green |
Green & Blue |
| Display* |
24 inch |
24 inch |
| Adapters* |
Adaptability for camera or assitant scope |
Adaptability for camera or assitant scope |
| Foot Switch Function |
Single-axis (Z) foot control |
Multi-axial (XYZ)Foot control* (* XY optional) |
| Stand |
Floor stand |
Floor stand |
| Dimensions (WxH) |
1140 mm x 1776 mm |
1140 mm x 1776 mm |
| Weight |
100 Kg (without XY) |
120 Kg (With XY) |
